Gamia Wood Spiral Stair Kit
The Gamia Wood spiral stair combines the warm look of solid Beech treads with the strength of a sleek steel framework. Available in a number of tread and metalwork colours to ensure it looks perfect in any setting.
| Gamia Wood Spiral Stair Kit - Information | |||
| Construction: | Manufactured in Steel & Timber (Solid Beech) | ||
| Spiral Rotation: | Clockwise or Anti-clockwise | ||
| Application: | Indoor use | ||
| Metalwork Colour Option: | Black (RAL 9017) Silver Grey (RAL 9006) |
||
| Stair Diameter Choice: | 1200mm | 1400mm | 1600mm |
| Recommended Opening Size: |
1200mm Diameter = 1250mm Opening 1400mm Diameter = 1450mm Opening 1600mm Diameter = 1650mm Opening |
||
| Floor to Floor Heights: | 2100mm to 2760mm (Standard Kit) 2761mm to 3680mm (requires additional Tread Kit(s)) - see Technical Data section |
||
| Individual Rise: | adjustable from 210mm to 230mm N.B Rises from 200 to 210mm & 230 to 240mm are possible with baluster adjustments made at the point of assembly |
||
| No. of Treads (Standard Gamia Wood Kit): |
11 Treads + 1 Landing Tread | ||
| Tread Detail: | Solid 38mm thick Beech Treads (clear varnished) either in a Natural or Dark Walnut colour option - see Product Images |
||
| Tread Dimensions: | View the Gamia Wood Tread Dimensions document | ||
| Tread Angles | 1200mm Diameter = 30° 1400mm Diameter = 30° 1600mm Diameter = 30° |
||
| Landing Tread: | Universal design - fits a circular or square landing opening | ||
| Landing Tread Dimensions: | View the Gamia Wood Landing Tread Dimensions document | ||
| Handrail Type: | Black / Grey Polyethylene (42mm diameter) - smooth finish - matches chosen metalwork colour |
||
| Balustrade Detail: | Made up of 22mm steel balusters | ||
| Spiral Stair Layout: | View the Gamia Wood Technical Data document | ||
| Optional Upper Floor Balustrade Kit: | See the Accessories List for the available Upper Floor Balustrade components | ||
| Optional Riser Bar Kit: | Complete with 11 steel bars, one fitted to each tread so it conforms to the 100mm gap rule (Building Regs) N.B You will need to check with your local building authority to make sure the Gamia Wood for your application is acceptable with Riser Bars. |
||
| Stair Installation: | Refer to the "Installation Video" (Product Images) & the Gamia Wood Installation Instructions. |
||
| Package Dimensions & Weight: |
1140mm x 940mm x 570mm; 1200mm Diameter - Weight = 180 kgs 1400mm Diameter - Weight = 196 kgs 1600mm Diameter - Weight = 214 kgs |
||
| Gamia Wood Spiral Stair Kit - Heights | |||
| Staircase Height | No. of Rises | Tread Kits Required | Column Kit Required |
|---|---|---|---|
| 2100 mm - 2300 mm | 10 | - | - |
| 2310 mm - 2530 mm | 11 | - | - |
| 2520 mm - 2760 mm | 12 | -------------- (Standard Kit) -------------- | |
| 2730 mm - 2990 mm | 13 | 1 | - |
| 2940 mm - 3220 mm | 14 | 2 | - |
| 3150 mm - 3450 mm | 15 | 3 | 1 * |
| 3360 mm - 3680 mm | 16 | 4 | 1 * |
* The Column Kit (Small Centre Post) is required for the Gamia Wood Spiral Stair Kit to achieve higher floor heights up to 3680mm.
This product is not on a 1-3 working days schedule.
It comes directly from our supplier as we do not hold stock.
This is a made to order / bespoke product (not marked as ‘Estimated Delivery 1-3 days’) and once the manufacturing process has been started, you will not be able to cancel your order. If a cancellation enquiry is made and manufacturing has not started then we will issue a full refund back onto the same payment type as the product(s) were first purchased.
The delivery timescale is referenced at the top of the product page and will be confirmed to you at the time of order.
Please read our full terms and conditions regarding the delivery procedure.
The delivery will be made by a transport carrier organised by the manufacturer, so it is important that you provide a contact telephone number.
As the transport carrier will contact you 24 hours prior to the delivery being scheduled.
Deliveries are usually made between 8:00am to 6:00pm Monday to Friday (excludes Bank Holidays).
Orders can be placed on our website for delivery destinations within the UK Mainland (England, Wales and Scotland).
For delivery destinations situated in the Highlands & Islands, Isle of Wight, Channel Islands, Isle of Man and Northern Ireland, please contact our Sales Office by email - [email protected] to obtain a transport costing for the product.
For European or most Worldwide delivery destinations please email our Sales Office - [email protected] with your enquiry detailing the product you are interested in, together with your full delivery address and contact information.
We can then return a Quotation for the product and delivery costs once this has been sourced from the transport company.
Important - please read before purchase
Fixed Ladders, Space Savers, Spirals and Loft Stairs are covered in the building regulations and we recommend you confirm with the Local Building Control Department regarding their suitability for any project prior to specifying.
Therefore it is your responsibility to ensure that any local authority approvals necessary have been obtained. This will vary according to your application and we advise you to always check before going ahead with a purchase.
Many of our products have been widely used in the past in conjunction with Building Control, but the interpretation of the requirements for any particular situation remains solely with your Local Building Control Department.
