Gamia Wood Deluxe Spiral Stair Kit (1200mm)
The Gamia Wood Deluxe Spiral Staircase Kit (1200mm) features solid beech treads and a strong steel framework, similar to that of the original, but replaces the black plastic handrail with a beautiful solid beech handrail. With all Gamia products there is an option of colours for both metalwork and woodwork.
|Gamia Wood Deluxe Spiral Stair Kit - Information|
|Construction:||Manufactured in Steel & Timber (Solid Beech)|
|Spiral Rotation:||Clockwise or Anti-clockwise|
|Metalwork Colour Option:||Black (RAL 9017)
Silver Grey (RAL 9006)
|Stair Diameter Choice:||1200mm|
|Recommended Opening Size:||1200mm Diameter = 1250mm Opening|
|Floor to Floor Heights:||2100mm to 2760mm (Standard Kit)
2761mm to 3680mm (requires additional Tread Kit(s))
- see Technical Data section
|Individual Rise:||adjustable from 210mm to 230mm
Rises from 200 to 210mm & 230 to 240mm are possible with baluster adjustments made at the point of assembly
|No. of Treads
(Standard Gamia Wood Kit):
|11 Treads + 1 Landing Tread|
|Landing Tread:||Universal design - fits a circular or square landing opening|
|Tread Angles||1200mm Diameter = 30°|
|Handrail Type:||Solid Beech (Inc two coats of clear varnish)|
|Balustrade Detail:||Made up of 20mm steel balusters|
|Tread Detail:||Solid 38mm thick Beech Treads (clear varnished)
either in a Natural or Dark Walnut colour option - see Product Images
|Optional Upper Floor Balustrade Kit:||See the "Accessories List" (Downloads section) for the available Upper Floor Balustrade components|
|Optional Riser Bar Kit:||Complete with 11 steel bars, one fitted to each tread so it conforms to the 100mm gap rule (Building Regs)
N.B You will need to check with your local building authority to make sure the Gamia Wood for your application is acceptable with Riser Bars.
|1140mm x 940mm x 570mm;
1200mm Diameter - Weight = 180 kgs
|Gamia Wood Deluxe Spiral Stair Kit - Heights|
|Staircase Height||No. of Rises||Tread Kits Required||Handrail Kits Required||Column Kits|
|2100 mm - 2300 mm||10||-||-||-|
|2310 mm - 2530 mm||11||-||-||-|
|2520 mm - 2760 mm||12||-------------- (Standard Kit) --------------|
|2730 mm - 2990 mm||13||1 *||1||-|
|2940 mm - 3220 mm||14||2 *||2||1 **|
|3150 mm - 3450 mm||15||3 *||3||1 **|
|3360 mm - 3680 mm||16||4 *||4||1 **|
* If one or more Tread kits have been applied to the Spiral Stair then it will be necessary to purchase the supplementary Handrail kit. This is required so the climbing balustrade can be extended to reach the landing floor.
** The Column Kits (Small Centre Post) are required for the Gamia Wood Deluxe Spiral Stair Kit to achieve higher floor heights up to 3680mm.
Free UK Mainland Delivery *
Within 1-3 working days, once the product has been despatched. Deliveries are usually made between 8:00am to 6:00pm Monday to Friday (excludes Bank Holidays).
Orders placed before 11:00am will be despatched the same day (stock dependent) for delivery the next working day.
When placing your order please provide a contact telephone number as this is a requirment of the specialist carrier we use.
Please read our full terms and conditions regarding the delivery procedure.
* There will be an additional transport charge for making deliveries to the following post codes situated in the Highlands & Islands, Isle of Wight, Channel Islands, Isle of Man and Northern Ireland -
|Post Code List|
|IV1, IV2, IV3, IV4, IV6, IV7, IV8, IV9, IV10, IV11, IV12, IV13, IV14, IV15, IV16, IV17, IV18, IV19, IV20, IV21, IV22, IV23, IV24, IV25, IV26, IV27, IV28, IV36, IV40, IV41, IV42, IV43, IV44, IV45, IV46, IV47, IV48, IV49, IV51, IV52, IV53, IV54, IV55, IV56, IV63|
|ZE1, ZE2, ZE3|
|TR21, TR22, TR23, TR24, TR25|
|PH19, PH20, PH21, PH22, PH23, PH24, PH25, PH26, PH30, PH31, PH32, PH33, PH34, PH35, PH36, PH37, PH38, PH39, PH40, PH41, PH42, PH43, PH44, PH49, PH50|
|PA20, PA36, PA38, PA39, PA40, PA41, PA42, PA43, PA44, PA45, PA46, PA47, PA48, PA49, PA50, PA60, PA61, PA62, PA63, PA64, PA65, PA66, PA67, PA68, PA69, PA70, PA71, PA72, PA73, PA74, PA75, PA76, PA77, PA78|
|KW1, KW2, KW3, KW5, KW6, KW7, KW8, KW9, KW10, KW11, KW12, KW13, KW14|
|HS1, HS2, HS3, HS4, HS5, HS6, HS7, HS8, HS9|
|PO30, PO31, PO32, PO33, PO34, PO35, PO36, PO37, PO38, PO39, PO40, PO41|
|GY, JY, IM, BT|
You will not be able to place an order online if you require delivery to a post code (featured above).
Instead you will need to contact our Sales office on 01243 785 246 for the additional transport charge associated with delivering the product to your address.
A member of our Sales team will be able to take your order over the telephone and payment can be made via Debit or Credit card.
Once a product has been despatched the standard delivery timescale for Scottish Highlands & Islands, Northern Ireland, Isle of Man and the Channel Islands will be 3-5 working days.
For European or most Worldwide delivery destinations please email our Sales Office - firstname.lastname@example.org with your enquiry detailing the product you are interested in, together with your full delivery address and contact information.
We can then return a Quotation for the product and delivery costs once this has been sourced from the transport company.
Important - please read before purchase
Fixed Ladders, Space Savers, Spirals and Loft Stairs are covered in the building regulations and we recommend you confirm with the Local Building Control Department regarding their suitability for any project prior to specifying.
Therefore it is your responsibility to ensure that any local authority approvals necessary have been obtained. This will vary according to your application and we advise you to always check before going ahead with a purchase.
Many of our products have been widely used in the past in conjunction with Building Control, but the interpretation of the requirements for any particular situation remains solely with your Local Building Control Department.
