Gamia Metal Spiral Stair Kit
The Gamia Metal’s contemporary design gives the stair a very sleek and modern feel. Available in a variety of diameters and able to suit a range of heights, the Gamia Metal is a bespoke item designed to suit each application perfectly.
|Gamia Metal Spiral Stair Kit - Information|
|Construction:||Manufactured in Steel|
|Spiral Rotation:||Clockwise or Anti-clockwise|
|Metalwork Colour Option:||Light Grey (comes with black balusters)
or Silver Grey (comes with silver grey balusters)
|Stair Diameter Choice:||1200mm||1400mm||1600mm|
|1200mm Diameter = 1250mm Opening
1400mm Diameter = 1450mm Opening
1600mm Diameter = 1650mm Opening
|Floor to Floor Heights:||2100mm to 2760mm (Standard Kit)
2761mm to 3680mm (requires additional Tread Kit(s))
- see Technical Data section
|Individual Rise:||adjustable from 210mm to 230mm
Rises from 200 to 210mm & 230 to 240mm are possible with baluster adjustments made at the point of assembly
|No. of Treads
(Standard Gamia Wood Kit):
|11 Treads + 1 Landing Tread|
|Landing Tread:||Universal design - fits a circular or square landing opening|
|Tread Angles||1200mm Diameter = 30°
1400mm Diameter = 30°
1600mm Diameter = 30°
|Handrail Type:||Black Polyethylene (42mm diameter) - smooth finish|
|Balustrade Detail:||Made up of 20mm steel balusters|
|Tread Detail:||Steel structure (with self adhesive black rubber strips)|
|Optional Upper Floor Balustrade Kit:||See the "Accessories List" (Downloads section) for the available Upper Floor Balustrade components|
|Optional Riser Bar Kit:||Complete with 11 steel bars, one fitted to each tread so it conforms to the 100mm gap rule (Building Regs)
N.B You will need to check with your local building authority to make sure the Gamia Metal for your application is acceptable with Riser Bars.
|1140mm x 940mm x 570mm;
1200mm Diameter - Weight = 166 kgs
1400mm Diameter - Weight = 177 kgs
1600mm Diameter - Weight = 205 kgs
|Gamia Metal Spiral Stair Kit - Heights|
|Staircase Height||No. of Rises||Tread Kits Required||Column Kits|
|2100 mm - 2300 mm||10||-||-|
|2310 mm - 2530 mm||11||-||-|
|2520 mm - 2760 mm||12||-------------- (Standard Kit) --------------|
|2730 mm - 2990 mm||13||1|
|2940 mm - 3220 mm||14||2||1 *|
|3150 mm - 3450 mm||15||3||1 *|
|3360 mm - 3680 mm||16||4||1 *|
* The Column Kits (Small Centre Post) are required for the Gamia Metal Spiral Stair Kit to achieve higher floor heights up to 3680mm. Also supplied with the Column Kit will be an extra section of Black Polyethylene Handrail.
This product is not on a 1-3 working days schedule.
It comes directly from our supplier as we do not hold stock.
The delivery timescale is referenced at the top of the product page and will be confirmed to you at the time of order.
Please read our full terms and conditions regarding the delivery procedure.
The delivery will be made by a transport carrier organised by the manufacturer, so it is important that you provide a contact telephone number.
As the transport carrier will contact you 24 hours prior to the delivery being scheduled.
Deliveries are usually made between 8:00am to 6:00pm Monday to Friday (excludes Bank Holidays).
Orders can be placed on our website for delivery destinations within the UK Mainland (England, Wales and Scotland).
For delivery destinations situated in the Highlands & Islands, Isle of Wight, Channel Islands, Isle of Man and Northern Ireland, please contact our Sales Office by email - firstname.lastname@example.org to obtain a transport costing for the product.
For European or most Worldwide delivery destinations please email our Sales Office - email@example.com with your enquiry detailing the product you are interested in, together with your full delivery address and contact information.
We can then return a Quotation for the product and delivery costs once this has been sourced from the transport company.
Important - please read before purchase
Fixed Ladders, Space Savers, Spirals and Loft Stairs are covered in the building regulations and we recommend you confirm with the Local Building Control Department regarding their suitability for any project prior to specifying.
Therefore it is your responsibility to ensure that any local authority approvals necessary have been obtained. This will vary according to your application and we advise you to always check before going ahead with a purchase.
Many of our products have been widely used in the past in conjunction with Building Control, but the interpretation of the requirements for any particular situation remains solely with your Local Building Control Department.
