Dolle Toronto Outdoor Spiral Stair Kit
The Toronto outdoor spiral staircase has been designed for both indoor and outdoor use. With its use of galvanised steel It makes for a strong and compact design allowing the user to make a safe and comfortable climb each time.
| Dolle Toronto Outdoor Spiral Stair Kit - Information | ||
| Construction: | Manufactured in Steel with a hot-dip galvanised finish | |
| Spiral Rotation: | Clockwise or Anti-clockwise | |
| Application: | Outdoor or Indoor use | Stair Diameter Choice: | 1250mm | 1550mm |
| Recommended Opening Size: |
1250mm Diameter = 1350mm Opening 1550mm Diameter = 1650mm Opening |
|
| Floor to Floor Heights: | 2460 to 2820mm (Standard Kit) 2665mm to 3760mm (requires additional Tread Kit(s)) - see Technical Data section |
|
| Individual Rise: | adjustable from 205mm to 235mm | |
| No. of Treads (Standard Toronto Kit): |
11 Treads + 1 Landing Tread | |
| Landing Tread: | Triangular design complete with its own balustrade section | |
| Tread Angles | 1250mm Diameter = 23° 1550mm Diameter = 29° |
|
| Handrail Type: | Flexible 40mm PVC handrail | |
| Balustrade Detail: | Made up of 20mm galvanised steel balusters | |
| Tread Detail: | Steel with a hot-dip galvanised finish (includes non-slip perforations) View the Toronto Tread Design document |
|
| Optional Upper Floor Balustrade Kit: |
Available in 1000mm length packs - Supplied with 9 x Balusters, a section of handrail & baserail plus fittings Prices on application, please email for a quotation |
|
| Installation assistance: | Please view the Manufacturers Installation Video 🎥 | |
| Dolle Toronto Outdoor Spiral Stair Kit - Dimensions | |||
| Staircase Height | No. of Rises | No. of Treads | Diameter Ø |
|---|---|---|---|
| 2460 mm - 2820 mm | 12 | 11 + 1 Landing Tread | 1250 mm or 1550mm |
| 2665 mm - 3055 mm | 13 | 12 + 1 Landing Tread | 1250 mm or 1550mm |
| 2870 mm - 3290 mm | 14 | 13 + 1 Landing Tread | 1250 mm or 1550mm |
| 3075 mm - 3525 mm | 15 | 14 + 1 Landing Tread | 1250 mm or 1550mm |
| 3280 mm - 3760 mm | 16 | 15 + 1 Landing Tread | 1250 mm or 1550mm |
Free UK Mainland Delivery *
Within 3-5 working days, once the product has been despatched. Deliveries are usually made between 8:00am to 6:00pm Monday to Friday (excludes Bank Holidays).
Please read our full terms and conditions regarding the delivery procedure.
* There will be an additional transport charge for making deliveries to the following post codes situated in the Highlands & Islands, Isle of Wight, Channel Islands, Isle of Man and Northern Ireland -
| Post Code List |
| IV1, IV2, IV3, IV4, IV6, IV7, IV8, IV9, IV10, IV11, IV12, IV13, IV14, IV15, IV16, IV17, IV18, IV19, IV20, IV21, IV22, IV23, IV24, IV25, IV26, IV27, IV28, IV36, IV40, IV41, IV42, IV43, IV44, IV45, IV46, IV47, IV48, IV49, IV51, IV52, IV53, IV54, IV55, IV56, IV63 |
| ZE1, ZE2, ZE3 |
| TR21, TR22, TR23, TR24, TR25 |
| PH19, PH20, PH21, PH22, PH23, PH24, PH25, PH26, PH30, PH31, PH32, PH33, PH34, PH35, PH36, PH37, PH38, PH39, PH40, PH41, PH42, PH43, PH44, PH49, PH50 |
| PA20, PA36, PA38, PA39, PA40, PA41, PA42, PA43, PA44, PA45, PA46, PA47, PA48, PA49, PA50, PA60, PA61, PA62, PA63, PA64, PA65, PA66, PA67, PA68, PA69, PA70, PA71, PA72, PA73, PA74, PA75, PA76, PA77, PA78 |
| KW1, KW2, KW3, KW5, KW6, KW7, KW8, KW9, KW10, KW11, KW12, KW13, KW14 |
| KA27, KA28 |
| HS1, HS2, HS3, HS4, HS5, HS6, HS7, HS8, HS9 |
| PO30, PO31, PO32, PO33, PO34, PO35, PO36, PO37, PO38, PO39, PO40, PO41 |
| GY, JY, IM, BT |
You will not be able to place an order online if you require delivery to a post code (featured above).
Instead you will need to contact our Sales office on 01243 785 246 for the additional transport charge associated with delivering the product to your address.
A member of our Sales team will be able to take your order over the telephone and payment can be made via Debit or Credit card.
Once a product has been despatched the standard delivery timescale for Scottish Highlands & Islands, Northern Ireland, Isle of Man and the Channel Islands will be 5-7 working days.
For European or most Worldwide delivery destinations please email our Sales Office - [email protected] with your enquiry detailing the product you are interested in, together with your full delivery address and contact information.
We can then return a Quotation for the product and delivery costs once this has been sourced from the transport company.
Important - please read before purchase
Fixed Ladders, Space Savers, Spirals and Loft Stairs are covered in the building regulations and we recommend you confirm with the Local Building Control Department regarding their suitability for any project prior to specifying.
Therefore it is your responsibility to ensure that any local authority approvals necessary have been obtained. This will vary according to your application and we advise you to always check before going ahead with a purchase.
Many of our products have been widely used in the past in conjunction with Building Control, but the interpretation of the requirements for any particular situation remains solely with your Local Building Control Department.
