Fakro LWT Passive House Timber Folding Loft Ladder
The LWT Passive House loft ladder is a comprehensive solution designed for passive buildings where a large emphasis is placed on minimizing heat loss. Supplied with an installation kit that forms an insulated seal at the ceiling level and reduces thermal bridges.
- The LWT Passive House Loft Ladder has been designed to meet the requirements for passive building standards
and comes fully certified. - Supplied as a complete unit with a white faced trapdoor, timber casing and ladder for quick and easy installation.
- Provided with an installation kit that forms an insulated seal at the ceiling level and reduces thermal bridges.
- Available in a range of loft opening sizes - see Technical Data section.
- Pine ladder with 80mm deep non-slip treads folding into 3 sections.
- Suits floor to ceiling heights up to 3.05m.
- Supplied with 1 x Red Metal Handrail as standard - see Product Images.
- Draught proofed and 80mm deep insulation to trapdoor providing a U-value: 0.51 W/m²K.
- No storage space needed in the loft as ladder stores completely on hatch.
- Operating pole included.
- Pair of plastic ladder feet (black) included.
- For Loft Ladder operating space - see LWT Passive House Technical Specification document.
- Optional 2nd side Metal Handrail (red colour) available.
- Optional Metal Loft Exit Grab Rails measure 900mm high & 515mm wide (available in black) - see Product Images.
- Tested and certified to EN 14975 (European Ladder Standard).
- Class 4 air permeability certified - tested to EN 12207.
- Max working load: 160 kg.
- 3 year Manufacturer's Warranty
| Fakro LWT Passive House Loft Ladder - Technical Info | |
| Ladder Type: | 3 Section Folding |
| Maximum Ceiling Height: | 3050mm - See Chart below |
| Opening Sizes: | See Chart below |
| Casing Frame Sizes: | See Chart below |
| U-Value: | 0.51 W/m²K |
| Ladder Angle: | 70° |
| Ladder Width: | 380mm |
| Ladder Tread Depth: | 80mm |
| Ladder Tread Thickness: | 20mm |
| Useable Tread Width: | 340mm |
| Trapdoor Thickness: | 80mm |
| String Thickness: | 20mm |
| String Depth: | 80mm |
| Casing Frame Height: | 220mm |
| Casing Frame Thickness: | 20mm |
| Tread Rise: | 250mm |
| Additional Dimensions: | see Technical Specification document |
| Fakro LWT Passive House Loft Ladder - Sizes | |||
| Ceiling Height | Product Sizes | ||
|---|---|---|---|
| 2340 - 2800mm | 1220mm (Structural Opening Length) 1184mm (Casing Frame Length) |
x | 620mm (Structural Opening Width) 580mm (Casing Frame Width) |
| 1220mm (Structural Opening Length) 1184mm (Casing Frame Length) |
x | 720mm (Structural Opening Width) 680mm (Casing Frame Width) |
|
| 1320mm (Structural Opening Length) 1284mm (Casing Frame Length) |
x | 720mm (Structural Opening Width) 680mm (Casing Frame Width) |
|
| 1420mm (Structural Opening Length) 1384mm (Casing Frame Length) |
x | 720mm (Structural Opening Width) 680mm (Casing Frame Width) |
|
| 2550 - 3050mm | 1320mm (Structural Opening Length) 1284mm (Casing Frame Length) |
x | 620mm (Structural Opening Width) 580mm (Casing Frame Width) |
| 1320mm (Structural Opening Length) 1284mm (Casing Frame Length) |
x | 720mm (Structural Opening Width) 680mm (Casing Frame Width) |
|
| 1420mm (Structural Opening Length) 1384mm (Casing Frame Length) |
x | 720mm (Structural Opening Width) 680mm (Casing Frame Width) |
|
This product is not on a 1-3 working days schedule.
It comes directly from our supplier as we do not hold stock.
This is a made to order / bespoke product (not marked as ‘Estimated Delivery 1-3 days’) and once the manufacturing process has been started, you will not be able to cancel your order. If a cancellation enquiry is made and manufacturing has not started then we will issue a full refund back onto the same payment type as the product(s) were first purchased.
The delivery timescale is referenced at the top of the product page and will be confirmed to you at the time of order.
Please read our full terms and conditions regarding the delivery procedure.
The delivery will be made by a transport carrier organised by the manufacturer, so it is important that you provide a contact telephone number.
As the transport carrier will contact you 24 hours prior to the delivery being scheduled.
Deliveries are usually made between 8:00am to 6:00pm Monday to Friday (excludes Bank Holidays).
Orders can be placed on our website for delivery destinations within the UK Mainland (England, Wales and Scotland).
For delivery destinations situated in the Highlands & Islands, Isle of Wight, Channel Islands, Isle of Man and Northern Ireland, please contact our Sales Office by email - sales@loftcentre.co.uk to obtain a transport costing for the product.
For European or most Worldwide delivery destinations please email our Sales Office - sales@loftcentre.co.uk with your enquiry detailing the product you are interested in, together with your full delivery address and contact information.
We can then return a Quotation for the product and delivery costs once this has been sourced from the transport company.
Important - please read before purchase
Fixed Ladders, Space Savers, Spirals and Loft Stairs are covered in the building regulations and we recommend you confirm with the Local Building Control Department regarding their suitability for any project prior to specifying.
Therefore it is your responsibility to ensure that any local authority approvals necessary have been obtained. This will vary according to your application and we advise you to always check before going ahead with a purchase.
Many of our products have been widely used in the past in conjunction with Building Control, but the interpretation of the requirements for any particular situation remains solely with your Local Building Control Department.
